SFX platform transporter with capacities of 55,000, 88,000 and 143,000 lbs
SFX platform transporter with capacities of 55,000, 88,000 and 143,000 lbs
New SFX platform transporter – optionally available with trailer coupling and Blue Arrow directional indicator
New SFX platform transporter – lighting equipment ensures greater safety

Free-moving platform transporters

for in-plant heavy-duty transport

  • Schwerlastplattform SFXLoad capacity
    up to 130 t
  • Schwerlastplattform SFXCompact
    platform height
  • AGV ready       AGV-ready

The transport of heavy and bulky loads presents a particular challenge. HUBTEX is able to meet this challenge with heavy-duty platforms in its new SFX series. The compact, self-propelled heavy-duty transport vehicles for indoor and outdoor use have a large loading area for transporting bulky, heavy loads.

  •  Electric drive, quiet and environmentally friendly
  •  Electric battery, maintenance-free AC drive technology
  •  2-way and multidirectional steering
  •  Four different operating variants (cabin, driver station, remote control or automation)
  •  Robust design



The SFX heavy-duty platform transporter in action

Heavy-duty transport with the SFX
Benefit from a coordinated vehicle concept

Typical applications would be in-plant heavy-duty transport within the automotive and aviation industries and especially along the value chain of the metal processing industry, from foundry to trade to processing, and many other areas for example in mechanical engineering. A solution tailor made to the application will offer you maximum benefit, high vehicle availability and a long service life.

Video Player is loading.
Current Time 0:00
Duration 1:05
Loaded: 12.27%
Stream Type LIVE
Remaining Time 1:05

1x
    • Chapters
    • descriptions off, selected
    • captions off, selected
    • original, selected

    Modular system for individual adaptations

    The high degree of modularity offered by the new heavy-duty platforms makes these vehicles adaptable to a wide range of applications. The frame of the new SFX is divided into three fixed areas front axle, rear axle and center section. Variability at the interfaces of the subassemblies facilitates order-specific adaptation of the length and width compatible to the transport task. Prefabricated modules, such as the wheel stool or the load wheel and drive rocker guarantee universal vehicle standards.

    Video Player is loading.
    Current Time 0:00
    Duration 1:20
    Loaded: 9.89%
    Stream Type LIVE
    Remaining Time 1:20

    1x
      • Chapters
      • descriptions off, selected
      • captions off, selected
      • original, selected

      Steering systems suitable for every application

      There are two different steering systems available for our platform transporters. We will recommend the appropriate option for you based on your aisle widths and drive-in situations. The 2-way steering is the standard variant for many applications. With small aisle widths, multidirectional steering is often recommended.

      SFX platform transporter controlled via radio remote control

      Simple and proven operation

      The standard operation of our platform transporters is via radio remote control. Operation is via joysticks for precision control, button for emergency stop, horn as well as flexibly expandable options. If necessary, a cable remote control can also be used. This can be connected to the vehicle via several plug-in ports. Alternatively, operation can be from a cabin or driver station. This is especially suitable for journeys over long distances. Should drivers be required to get on and off the vehicle frequently, a variant with a stand up cabin is recommended.



      Equipment
      For comfortable and efficient handling

      Blei Säure Batterie im Einsatz

      Custom-fit battery and charging concept

      A lead-acid or lithium-ion battery is available as an option for our SFX heavy-duty transporters. Classic lead-acid batteries have a charging time of five and a half to fourteen hours depending on the type of battery charger, with an average of 1200 charging cycles and comparatively low investment costs. These batteries reach their capacity limits in multi-shift usage with high operating hours. In this setting, we recommend either a battery change or a lithium-ion battery. These can be fully charged from one hour, offer unlimited boost charging, have a low weight and can complete up to 6000 cycles.

      rgba(46,51,56,1)

      We can create a customized offer

      Our platform transporters are ideal for in-plant heavy-duty transport. There are a number of different configuration options to choose from – a solution designed precisely for the application offers you maximum benefit, high device availability and a long service life. We will be happy to help you find the best possible solution for your application.

      The new SFX platform transporter for in-plant heavy-duty transport, AGV ready

      Vehicle specifications
      for the SFX platform transporter



      • Load capacity
        Up to 130 tons
      • Steering
        2-way and multidirectional steering
      • Drive
        Electric drive
      • Platform height
        From 457 mm
      • Frame
        Variable in length & width
      • Tires
        PU or soft tires

      Overview of SFX models
      The right model for your application

      25 t load capacity

      2-way steering

      PU soft tires

      910 mm platform height

      SFX 25

      Schwerlastplattform SFX 25

      40t load capacity

      2-way or multidirectional steering

      PU or PU soft tires

      910 mm platform height

      SFX 40

      SFX platform transporter with capacities of 55,000, 88,000 and 143,000 lbs

      65t load capacity

      2-way or multidirectional steering

      PU or PU soft tires

      950 mm platform height

      SFX 65

      Schwerlastplattform SFX 65

      Up to 130 t load capacity

      2-way or multidirectional steering

      EL / PU / pneumatic tires

      Platform height from 457 mm

      SFX individual

      Free-traveling platform transporter for heavy-duty transport

      Gallery

      HUBTEX platform transporter with wireless coupling operation

      The optional wireless coupling of the platform transporter makes maneuvering possible even over long distances.

      SFX heavy-duty platform for in-plant heavy-duty transport
      Self-propelled heavy-duty platform SFX for indoor/outdoor use

      Special equipment
      Customized platform transporter for your heavy-duty transport

      The HUBTEX platform transporter with minimal overall height
      rgba(46,51,56,0.8)

      “Small but perfectly formed” – Minimum overall height

      The heavy-duty platform with the lowest overall height in the HUBTEX portfolio at just 457 mm has a load capacity of up to 35 tons. Impressively, the vehicle also has a platform lift of 203 mm. This means that the platform transporter, which is equipped with a wide variety of assistance systems, can independently drive under the load, lift it and transport it away.
